Product Details:
|
| Key Selling Points:: | Energy Saving | Machinery Test Report:: | Not Available |
|---|---|---|---|
| Warranty Of Core Components:: | 1 Year | Control Mode:: | Control Mode |
| After-sales Service Provided:: | Online Support | Showroom Location:: | None |
| Production Rate:: | 3 Nm³/H | Marketing Type:: | New Product 2022 |
| High Light: | 3nm3 PSA Nitrogen Machine,0.6mpa PSA Nitrogen Machine,95% PSA nitrogen system |
||
High Quality Cheap Price Custom PSA Nitrogen Gas Generator Machine
Description
The PSA nitrogen generator utilizes the difference in the adsorption capacity of different components in the gas medium on the adsorbent. The adsorbent is selectively adsorbed when the pressure is increased, and desorbed and regenerated when the pressure is decreased. In this way, the alternate cycle is continuously produced. Product nitrogen. In the case of adsorption equilibrium, when adsorbing the same gas, the higher the gas pressure, the greater the adsorption capacity of the adsorbent. Conversely, the lower the pressure, the smaller the adsorption capacity.
Parameter
| model: | AYAN-10LB |
| Nitrogen purity: | 95-99.999% (Note: Select the required purity before ordering, according to the purity) |
| Output flow: | 0-10L∕min |
| oxygen content | ≤0.01% |
| noise | 65dB |
| Output pressure: | 0-0.6Mpa (factory setting 0.5Mpa) |
| Working power: | 220V±10％﹔50HZ±5％ |
| High Power: | 2800W |
| Environmental conditions: | Ambient temperature: 10-40℃, relative humidity: ≤85%, no large amount of dust and corrosive gas |
| Dimensions: | 950﹡750﹡1200mm |
| weight: | 180Kg |
Features:
1. Quiet: air compressor cavity, air compressor vibration base, low noise and low vibration running with insulating materials.
2. Convenience: adjustable output nitrogen flow and output nitrogen pressure
3. Mobile: Provides casters that are easy to move, you can place the generator where you need it, and use the laboratory space.
4. Economy: more economical than other gas supply methods.
5. Intuitive: Comes with nitrogen purity display, blind spot for nitrogen purity.
Precautions
The drying tube of the PSA nitrogen generator should be replaced regularly. When 50% of the discolored silica gel in the drying tube is discolored, the internal packing should be replaced. Replacement: Turn off the power and bleed the system (pressure drop to zero). Unscrew the purification tube in the direction indicated by the arrow, unscrew the end cap of the purification tube, and replace the silica gel desiccant.
2. Bake the discolored silica gel in a 120°C oven for 12 hours. Molecular sieves were fired in a muffle furnace at 250°C-300°C for 24 hours.
3. When replacing the desiccant, it should be noted that all the absorbent cotton is put into the tube to ensure that there is no impact on the sealing end face, so as to ensure that the end cap can be sealed after being screwed.
4. Tighten it in the direction shown by the arrow during installation. Use soap liquid to check for leaks after starting the machine, and make sure it is sealed.
5. It is not allowed to wrap various sealing tapes on the thread surface of the drying pipe without authorization, otherwise the drying pipe will be cracked and cannot be sealed.
6. Regularly replenish distilled water to ensure that the liquid level is between the upper and lower limits.
