Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use

Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use
Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use

Large Image :  Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use

Product Details:
Place of Origin: CHINA
Brand Name: GNE
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: ≥1sets
Price: According to the product
Packaging Details: Wooden box packaging
Delivery Time: Transit time: Est. 17-24 days
Contact Now

Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use

Description
Voltage: 220V/380V 50Hz Product_Pressure: 0.1-0.8Mpa
Air Consumption: 10m3/min Flow: 3-2000Nm3/h
Product_Power_Supply: 220V/380V/400V/415V Customize: Available
Machinery Test Report: Provided Material: Carbon,stainless Steel
Oxygen Analyzer: Included Nitrogen Capacity: 1 ~100Nm3/h
Guarantee: 1 Year Life Span: 8-10 Years
Highlight:

0.1-0.8Mpa PSA Nitrogen Generator

,

3-2000Nm3/h Nitrogen Generation System

,

1 Year Guarantee Nitrogen Gas Generator

Large PSA Nitrogen Generator for Industrial Applications
Pressure Swing Adsorption (PSA) Technology
PSA technology separates gas species from a mixture under pressure based on molecular characteristics and affinity for adsorbent materials. Operating at near-ambient temperatures, it differs from cryogenic distillation methods. The process uses specific adsorptive materials (activated carbon, molecular sieves) to trap target gases at high pressure, then swings to low pressure to release them.
Product Specifications
Carbon Molecular Sieve Capacity (KG) Purity/Nitrogen Capacity (Nm³/h)
96% 97% 98% 99% 99.95% 99.98% 99.995% 99.999%
1205550454020151310
1507570655020201513
1808080706030222015
210105100908030252518
2401151101009040302720
Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use 0 Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use 1 Large Capacity PSA Nitrogen Generator with 0.1-0.8Mpa Pressure Range and 3-2000Nm3/h Flow Rate for Industrial Use 2
Industrial Applications
  • Food Packaging: Bread, cakes, fruits, snacks, beer preservation
  • Pharmaceutical Industry: Injection, infusion, filling processes
  • Chemical Industry: Nitrogen cover, press material, chemical fiber production protection gas
  • Other Industries: Metallurgy, coal, cable, oil & gas, laser cutting
GNEE Series PSA Nitrogen Generator Advantages
Specifications
  • Purity: 95-99.9999%
  • Capacity: 5-8000Nm³/h
  • Pressure out: 0-0.8Mpa (1.0~15.0MPa available)
  • Dew point: -45°C to -70°C
Technical Features
  • Imported pneumatic valves with 3+ million cycle lifespan
  • Siemens PLC intelligent program controller for stable operation
  • Inert ceramic balls diffusion technology for even airflow distribution
  • Self-force cylinder compression protects carbon molecular sieve
  • Centrifugal vibration filling ensures maximum adsorbent volume
Request a Quotation
Please provide the following details:
  • N2 flow rate: _____Nm³/hr
  • N2 purity: _____%
  • N2 discharge pressure: _____Bar
  • Voltages and Frequency: ______V/PH/HZ
  • Nitrogen application
  • Your local sea level
Packaging Details
Size 123 (L) * 456 (W) * 789 (D)
Weight 1.2 T
Packaging Method Standard wooden box packaging. European shipments include fumigation. Alternative packaging available for special requirements.
We also manufacture VPSA Oxygen Generators, PSA Oxygen Generators, storage tanks, and heat exchangers. For inquiries about our PSA nitrogen systems or other products, please contact us at info@gneeheatex.com.
