100Nm³/h 99.5% High-Purity PSA Oxygen Plant for Hospital Oxygen Supply Systems
The PSA Oxygen Plant (Pressure Swing Adsorption Oxygen Generator) is a medical-grade oxygen supply equipment based on pressure swing adsorption technology. It deeply purifies air through double-layer high-purity molecular sieves, enabling stable production of medical oxygen with 99.5% purity. This system features core advantages of high purity, stable operation, low noise, and simple operation.
As a core component of medical oxygen generation plants, the 100Nm³/h flow rate can meet the oxygen supply needs of general hospitals with 200-300 beds. It fully complies with the national standard "Medical Oxygen" (GB 8982-2014) and ISO 10083 medical gas specifications, and can be directly connected to hospital central oxygen supply systems.
Product Specifications
| 90% |
93% |
Approx. Weight and Dimensions |
| SCFH |
NM3/HR |
SCFH |
NM3/HR |
H (Inch) |
W (Inch) |
L (Inch) |
Weight (Lbs.) |
| 73 | 1.92 | 65 | 1.71 | 86 | 36 | 30 | 720 |
| 111 | 2.93 | 100 | 2.62 | 87 | 36 | 37 | 780 |
| 164 | 4.31 | 147 | 3.86 | 87 | 42 | 48 | 1728 |
| 207 | 5.44 | 185 | 4.86 | 93 | 42 | 48 | 1927 |
| 311 | 8.19 | 278 | 7.32 | 103 | 46 | 48 | 2630 |
| 414 | 10.89 | 371 | 9.74 | 106 | 50 | 53 | 4892 |
| 516 | 13.57 | 461 | 12.13 | 110 | 52 | 58 | 3851 |
| 724 | 19.03 | 647 | 17.02 | 97 | 54 | 60 | 4592 |
| 1237 | 32.52 | 1106 | 29.10 | 121 | 72 | 72 | 7576 |
| 1641 | 43.15 | 1468 | 38.60 | 116 | 74 | 88 | 9370 |
| 2107 | 55.40 | 1885 | 49.56 | 137 | 74 | 88 | 10882 |
| 2521 | 66.28 | 2255 | 59.29 | 135 | 84 | 112 | 15238 |
| 2918 | 76.72 | 2610 | 68.63 | 127 | 90 | 112 | 15602 |
| 3706 | 97.45 | 3315 | 87.18 | 147 | 90 | 112 | 16699 |
| 4101 | 107.83 | 3668 | 96.46 | 121 | 120 | 156 | 19988 |
| 4473 | 117.63 | 4002 | 105.23 | 127 | 120 | 156 | 20791 |
| 5033 | 132.33 | 4502 | 118.38 | 184 | 120 | 156 | 21774 |
Why Hospitals Prefer High-Purity PSA Oxygen Plants
Hospital oxygen supply is critical for medical safety, with oxygen purity directly affecting treatment outcomes. Traditional bottled oxygen presents three major challenges:
- Unstable supply - vulnerable to logistics disruptions from weather or inventory shortages
- High storage risks - requiring explosion-proof facilities for high-pressure cylinders
- High costs - 3-4 times more expensive than PSA oxygen plants when considering purchase, transport, and storage
The 99.5% high-purity oxygen from our PSA Oxygen Plant meets diverse medical requirements:
- Operating rooms and ICUs require high-purity oxygen for anesthesia and life support
- Neonatal and respiratory departments benefit from stable purity that reduces complication risks
The 100Nm³/h flow rate supports 30-40 oxygen terminals simultaneously, covering general hospital needs. Flow can be adjusted during peak hours via buffer tanks. Our PSA medical oxygen generator technology produces oxygen directly from air without chemicals, with operating costs just 1/4 of bottled oxygen - saving over 500,000 RMB annually.
Maintenance and Safety Management
Proper maintenance extends the PSA Oxygen Plant service life beyond 10 years while ensuring safety:
Daily Maintenance
- Daily checks of operating status and oxygen concentration
- Weekly cleaning of air intake filters and humidifier bottles
- Monthly replacement of pretreatment system filters
- Quarterly pipeline and valve leak detection
Core Component Care
- Test molecular sieve adsorption performance every 6 months
- Replace when purity drops below 95% (normal lifespan 2-3 years)
- Use only medical-grade molecular sieves
Environmental Requirements
- Maintain clean, dry equipment rooms
- Temperature: 15-30℃
- Humidity ≤60%
Safety Protocols
- Maintain operation logs and maintenance records
- Implement emergency backup systems (liquid oxygen tanks)
- Annual professional inspections by PSA oxygen generator manufacturers
Our PSA Oxygen Plant combines 99.5% purity with precise 100Nm³/h flow to become the safety standard for hospital oxygen systems. The pressure swing adsorption PSA oxygen plants technology meets medical compliance while reducing costs. With proper installation and maintenance, it delivers continuous, safe, economical oxygen supply.
