Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting

Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting
Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting

Large Image :  Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting

Product Details:
Place of Origin: CHINA
Brand Name: GNEE
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: ≥1sets
Price: According to the product
Packaging Details: Wooden Box / Outer shell packaging
Payment Terms: L/C,D/A,D/P,Western Union,MoneyGram
Contact Now

Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting

Description
Warranty: 1 Year Voltage: 220V/380V
Production Rate: 95-99.9995% Dimension(l*w*h): Customized
Weight: Actual Weight Color: Customized
Application: General Industrial Fields,Oil/Gas/Chemical/Metallurgy/Food/Coal Pressure: 0.1~0.7Mpa
Product Name: PSA Nitrogen Generator Type: Pressure Swing Adsorption(PSA)
Capacity: 1~5000m3/h Name: Small PSA Nitrogen Generator For Sale
Highlight:

High Purity 99.999% PSA Nitrogen Gas Generator

,

Portable N2 Generator Machine

,

Laser Cutting Nitrogen Generator

Portable PSA Nitrogen Gas Generator for Laser Cutting
A PSA nitrogen generator is a state-of-the-art gas separation system based on pressure swing adsorption technology, utilizing high-performance carbon molecular sieve (CMS) to isolate nitrogen from atmospheric air with exceptional selectivity. This portable variant combines ultra-compact design with high purity 99.999% N2 generation capabilities, delivering laboratory-grade nitrogen on demand for on-site metal processing.
Core Technical Specifications
Capacity (Nm³/h) Purity (%) Construction Dimensions (mm) Inlet & Outlet Weight (Kg)
595Four towers570*450*1300G1/4; G1/4253
599Four towers580*460*1450G1/4; G1/4295
599.5Four towers1000*900*1200DN20; G1/2"370
599.9Four towers1000*900*1500DN20; G1/2"431
599.99Four towers1200*1100*1350DN20; G1/2"535
599.999Four towers1300*1200*1700DN25; G1/2"698
599.999Two towers1100*600*1600DN25; G1/2"510
1095Four towers1000*900*1400DN20; G1/2"414
1099Four towers1100*1050*1400DN20; G1/2"485
1099.5Four towers1100*1050*1650DN20; G1/2"510
1099.9Four towers1200*1150*1850DN20; G1/2"624
1099.99Four towers1400*1300*1600DN25; G1/2"788
1099.999Four towers1500*1400*1850DN25; G1/2"1098
Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting 0 Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting 1 Portable PSA Nitrogen Gas Generator High Purity 99.999% N2 Generator Machine for Laser Cutting 2
Why 99.999% High Purity Matters for Laser Cutting
Laser cutting relies on nitrogen to displace oxygen, prevent workpiece oxidation, and ensure precise, clean cuts. For stainless steel and aluminum alloy cutting, 99.999% purity (oxygen content ≤50ppm) eliminates edge discoloration, rust formation, and micro-cracks, reducing post-processing costs by up to 40%. Carbon steel cutting benefits from 99.999% nitrogen for thicker materials (≥8mm), where residual oxygen can cause irregular edges and reduced cut speed.
PSA vs. VPSA Technology: Why Portability Favors PSA
PSA systems operate at higher pressure (0.6-1.0MPa) with compact adsorption towers, enabling integration into portable frames without sacrificing performance. Their fast startup time (3-5 minutes) and short cycle times (60-90 seconds) align with the intermittent operation of portable laser cutters. VPSA technology requires larger equipment, heavier vacuum pumps, and higher energy consumption—making it impractical for portable design.
Key Selection Considerations
  • Purity and Flow Rate Matching: Confirm the generator's rated purity and flow rate align with your laser cutter's specifications
  • Mobility and Durability: Evaluate weight, casters, and build quality for job site conditions
  • Energy Efficiency: Opt for models with energy-saving certifications or VFD technology
  • Ease of Operation: Choose units with intuitive digital controls and one-key startup
  • Manufacturer Support: Select reputable manufacturers with global service networks
  • Cost Transparency: Consider total cost of ownership rather than just initial purchase price
This portable PSA nitrogen generator is a transformative solution for the laser cutting industry, combining ultra-high purity, mobility, and energy efficiency. It eliminates the limitations of traditional nitrogen supply, enabling flexible, cost-effective metal processing across diverse job sites.
