Product Details:
|
| Place Of Origin: | Henan, China | Dimension(L*W*H): | 5680*2200*2200 |
|---|---|---|---|
| Warranty:: | 1 Year | Showroom Location: | None |
| Volume: | 5000litres-200,000litres | Color: | Customer's Request |
| Medium: | Fuel/diesel/petrol/Crude Oil/double Fuel Type | Advantage: | Anticorrosive |
| Local Service Location: | None | Marketing Type: | Ordinary Product |
| High Light: | 5000l underground residential oil tanks,200000l underground residential oil tanks,65 cubic meter oil holding tanks |
||
Underground Chemical Petroleum 65m3 Double-Layer Anti-Corrosion Large-Capacity Oil Storage Tank
Product introduction
SF double-layer tank is mainly made of reinforced glass fiber, which has strong corrosion resistance, earthquake resistance and pressure resistance, and is strong and durable, preventing potential leakage from the root. In order to prevent accidents, special detection equipment is installed inside the tank. Once the tank leaks, the detection equipment will sound the alarm in time, which improves the safety factor of the SF double-layer tank. Because the SF double-layer tank is double-layer structure, there is a gap between the inner steel shell and the outer reinforced glass layer fiber, even if leakage occurs, it can guarantee no leakage.
Specification
| Capacity (M3) | 20 | 30 | 40 | 50 | 60 | 70 |
| internal diameter(mm) | 2200 | 2400 | 2600 | 2800 | 2800 | 2800 |
| Tank of the length (mm) | 4500 | 5820 | 6700 | 7200 | 8800 | 10400 |
| Gap between two layer(mm) | 0.1-3.5 | 0.1-3.5 | 0.1-3.5 | 0.1-3.5 | 0.1-3.5 | 0.1-3.5 |
| Inner steel tank thickness(mm) | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 |
| Head thickness (mm) | ≥8 | ≥8 | ≥8 | ≥8 | ≥8 | ≥8 |
| External tank thickness(mm) | ≥4 | ≥4 | ≥4 | ≥4 | ≥4 | ≥4 |
| Manhole quantity | 2 | 2 | 2 | 2 | 2 | 2 |
| Manhole diameter(mm) | 600 | 600 | 600 | 600 | 600 | 600 |
Structure characteristics
1. Inner layer guarantee: the inner layer is processed with 6m thick high quality steel plate, which is the basic condition to ensure that the fuel will not leak or leak.
2. Outer layer optimization: the outer structure made of reinforced glass fiber is of strong corrosion resistance, seismic resistance, and durability.
3. Layer spacing: This is also the difference between SF double-layer tank and ordinary single-layer tank. The gap of 0.1m can prevent leakage and other hidden dangers from the root, and the safety factor is higher.
4. Monitoring equipment: the monitoring equipment can make round-the-clock and uninterrupted whole-course observation. If there is leakage, it can give alarm in time to ensure the safe use of SF double-layer tank.
The outer layer of the SF tank ensures that leaks do not directly contaminate the water or soil, protecting the ecological environment and protecting the internal steel shell from corrosion.
