500L-30000L Underground Diesel Fuel Oil Storage Tank 1.6MPa

Large Image : 500L-30000L Underground Diesel Fuel Oil Storage Tank 1.6MPa

Product Details:

Place of Origin:	CHINA
Brand Name:	GNEE
Certification:	SGS

Payment & Shipping Terms:

Minimum Order Quantity:	≥1sets
Price:	depend on product
Packaging Details:	Wooden box packaging / Outer shell packaging
Payment Terms:	MoneyGram,Western Union,T/T,D/P,D/A,L/C

Contact Now

500L-30000L Underground Diesel Fuel Oil Storage Tank 1.6MPa

Description

Loading Medium:	-196 - 0 ℃	Operating Pressure:	1.6MPa
Color:	White Or Based On Customer's Requirement	Height:	2591mm
Inner Vessel Material:	304 Stainless Steel	Placement Method:	Horizontal
Package:	Sea Or Land Transportation	Key Selling Points:	High Productivity
Item:	Cryogenic Pressure Tank (LO2,LN2,LAr)	Test Pressure:	0.8MPa-1.6MPa
Inner Vessel Type:	Double-walled	Inner Cylinder Material:	S30408
Highlight:	underground diesel fuel storage tank , high-pressure fuel oil storage tank 1.6MPa , large capacity diesel storage tank 30000L

High Quality 500L-30000L Underground Diesel Fuel Oil Storage Tank

Product Description

GNEE's underground steel tanks provide superior structural strength and product compatibility, designed to withstand the rigors of the underground environment. Available in single-layer, dual-layer and three-layer stainless steel configurations with or without agitation systems for product blending. Capacity ranges from 1000L to 30000L with custom larger sizes available.

Single-layer tanks are widely used in beverage, food, dairy, pharmaceutical, chemical and process industries as blender tanks, buffer tanks and storage tanks. All tanks are cleanable to meet sanitary standards including FDA and USDA requirements.

Product Parameters

Water capacity	Working pressure (MPA)	External dimension (mm)	Net weight (kg)	Full-load weight (kg)	LOX	LIN
5m3	1	2216*4405	4130	9830	8180	11130
5m3	1.75	2216*4405	4400	10100	8450	11400
10m3	1	2216*7098	6250	17920	14620	20520
10m3	1.75	2216*7098	6861	18261	14961	20861
15m3	0.8	2616*6520	7380	24480	22530	28380
15m3	1.75	2616*6520	8501	25601	20651	29501
20m3	0.8	2616*8030	8925	31725	25125	36925
20m3	1.75	2616*8030	10378	33178	26578	38378
30m3	0.8	2616*11070	12166	46366	36466	54166
30m3	1.75	2616*11070	14300	48500	38600	56300
50m3	0.8	3020*12685	19494	76494	59994	89494
50m3	1.75	3020*12685	23050	80050	63550	93050
100m3	0.8	3520*17585	33800	147800	114800	174800
100m3	1.6	3520*17585	40550	154550	121550	181550

Standard Configuration

Manhole
CIP cleaner
Adjustable triangle bracket
Ladder
Thermometer
Liquid level meter and controller
Eddy-proof board
Dismountable inlet assembly
Sanitary breathing cover
