ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3

ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3
ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3 ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3 ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3 ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3

Large Image :  ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3

Product Details:
Place of Origin: CHINA
Brand Name: GNEE
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: ≥1sets
Packaging Details: Customer's Requst/customization
Delivery Time: Transit time: Est. 17-24 days
Payment Terms: MoneyGram,Western Union,T/T,D/P,D/A,L/C
Contact Now

ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3

Description
Design Code: ASME Fillling Rate: 95%
Inner Vessel Type: Double Wall Application: Provided
Geometric Volume: 3 To 350M3 Advantage: High Efficiency
Loading Medium: -196 - 0 ℃ Size: Customer's Requst
Operating Pressure: 1.6 MPa Type: Customization
Outer Vessel Type: Single Wall Temperature Range: -196°C To 100°C
Highlight:

ASME LPG storage tank

,

customizable LPG pressure tank

,

cryogenic storage tank 350M3

Customizable Long-Life LPG Storage Tanks
Product Description
LPG storage tanks are designed for storing compressed liquefied petroleum gas (LPG), suitable for industrial, commercial, and residential applications. Constructed from high-strength low-alloy steel or carbon steel, these tanks feature customizable designs to meet diverse environmental and operational requirements.
The tank system consists of three main components:
  • Tank Body: Primary storage container with customizable diameter and length
  • Tank Bottom: Typically conical design to enhance liquid flow during unloading
  • Auxiliary Equipment: Includes pressure gauges, relief valves, thermometers, level indicators, and leak protection systems for operational safety
Technical Specifications
No. Dimension (mm) Net Weight (KG) Type
1 Φ1916*5172 3930 Vertical
2 Φ2316*5981 5840
3 Φ2316*8035 7900
4 Φ2716*7377 9250
5 Φ2920*8904 12600
6 Φ2920*11290 16000
7 Φ3220*11304 18700
8 Φ3420*14920 31200
9 Φ3420*18102 37200
10 Φ3724*22128 53200
11 Φ4024*24085 69400
12 Φ3220*11304 25600
13 Φ3520*17276 46300
ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3 0 ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3 1 ASME LPG Storage Tank 1.6 MPa Pressure Customizable 3-350M3 2
Key Advantages
  • Enhanced Safety: Complies with strict safety standards with low internal pressure design to minimize explosion and leakage risks
  • Optimized Storage: High-capacity design reduces transportation and storage costs per unit volume
  • Eco-Friendly: Environmentally compliant materials and manufacturing with minimal leakage impact
  • Durable Construction: High-quality materials resist wear and corrosion for extended service life
  • Versatile Application: Suitable for urban and rural environments with simple operation and maintenance
Contact for Custom Specifications
Email: info@gneeheatex.com
WhatsApp: +86 158 2468 7445

Tag:

Aboveground mounded LPG tank,

Anti Corrosion Storage Tank LPG,

1.77 MPa LPG Gas Storage Tank
