Product Details:
|
| Max Working Pressure(MPa): | 2.16 MPa | Machinery Test Report:: | Provided |
|---|---|---|---|
| Core Components: | Pressure Vessel | Volume: | 10m3 |
| Usage: | Store Liquid | Video Outgoing-inspection: | Provided |
| High Light: | 2.16MPa Cryogenic Storage Tank,10 cubic meter Cryogenic Storage Tank,5000L liquid n2 storage tank |
||
10m3 21.6ba liquid nitrogen N2 cryogenic storage tank
Description
The cryogenic liquid nitrogen storage tank is a large-scale super pressure vessel equipment for storing liquid nitrogen with double-layer vertical circular cylindrical vacuum insulation. The inner and outer materials are made of different steels, and the interlayer between the two layers is filled with expanded perlite. The specially treated adsorbent will keep the vacuum of the interlayer well and prevent the leakage and evaporation of liquid nitrogen inside the storage tank.
Parameter
| Effective volume(M3) | Working pressure(Bar) | Dimension(mm) | Weight(Kg) |
| 5 | 21.6 | 2000*5130 | 4450 |
| 10 | 21.6 | 2100*7170 | 6986 |
| 15 | 21.6 | 2500*6912 | 8810 |
| 20 | 21.6 | 2500*8756 | 11328 |
| 25 | 21.6 | 2900*7728 | 14660 |
| 30 | 21.6 | 2900*8875 | 17961 |
| 50 | 21.6 | 3200*11320 | 26097 |
| 60 | 21.6 | 3200*13180 | 30220 |
| 100 | 21.6 | 3500*16870 | 49627 |
Boosting range:
1. Check whether the pressure gauge and liquid level gauge of the cryogenic liquid nitrogen storage tank are in working condition.
2. Make sure that the gas passing valve is fully open.
3. Slowly open the front valve (booster valve) of the supercharger to make the liquid enter the supercharger to vaporize. If the discharge speed is fast and the pressure of the inner cylinder drops fast, the booster valve can be opened. When the pressure reaches the required working pressure, close down or completely close the front valve of the supercharger, at this time, the liquid in the supercharger will continue to evaporate to the required pressure. During the pressurization process, pay close attention to the change of the indicated value of the pressure gauge.
Advantage
The cryogenic liquid nitrogen storage tank adopts vacuum powder for heat preservation, which can ensure that the daily evaporation rate of the storage tank is low, the vertical structure can occupy a small area, save the space of the manufacturer, and the equipment of the overall storage tank can be centrally controlled and operated and maintained. convenient
