Product Details:
|
| Capacity: | 30 M3,100-20000L | Weight: | Customized,Actual Weight |
|---|---|---|---|
| Warranty: | 1 Year | Condition: | New |
| Dimension(l*w*h): | 2991mm X 2438mm X 2591mm,according To Capacity | Material: | Stainless Steel,carbon Steel |
| Color: | Based On Customer's Requirement | Type: | Vertical |
| Usage: | Cryogenic Liquid Storage,liquid Gas Storage Tank,Cryogenic Storage Tank,cryogenic Storage Dewar | Application: | Pharmaceutical,Fuel Oil,Cold Storage,Chemical,juice |
| Product Name: | Stainless Steel Storage Tank | Working Pressure: | 1-40Mpa |
| Working Medium: | LN2,LO2,LPG,LNG, | Design Temperature: | -196°C/50°C |
| Attribute | Value |
|---|---|
| Capacity | 30 m³, 100-20000L |
| Weight | Customized, Actual Weight |
| Warranty | 1 Year |
| Condition | New |
| Dimension (l×w×h) | 2991mm × 2438mm × 2591mm, according to capacity |
| Material | Stainless Steel, Carbon Steel |
| Color | Based on customer's requirement |
| Type | Vertical |
| Usage | Cryogenic liquid storage, liquid gas storage tank, Cryogenic Storage Tank, cryogenic storage dewar |
| Application | Pharmaceutical, Fuel Oil, Cold storage, Chemical, Juice |
| Working pressure | 1-40Mpa |
| Working medium | LN₂, LO₂, LPG, LNG |
| Design temperature | -196°C/50°C |
| Volume (m³) | Working Pressure (bar) | Dimension (mm) | Weight (KG) | Type | Standard |
|---|---|---|---|---|---|
| 5 | 21.6 | Φ2000×5130 | 4450 | Vertical | GB ASME |
| 10 | 21.6 | Φ2100×7170 | 6986 | ||
| 15 | 21.6 | Φ2500×6912 | 8810 | ||
| 20 | 21.6 | Φ2500×8756 | 11328 | ||
| 25 | 21.6 | Φ2900×7728 | 17961 | ||
| 30 | 21.6 | Φ2900×8875 | 14660 | ||
| 50 | 21.6 | Φ3200×11320 | 26097 | ||
| 60 | 21.6 | Φ3200×13180 | 30220 | ||
| 100 | 21.6 | Φ3500×16870 | 49627 |
