ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal

ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal
ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal

Large Image :  ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal

Product Details:
Place of Origin: CHINA
Brand Name: GNEE
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: ≥1sets
Price: depend on product
Payment Terms: ,L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: Annual Production 30,000 tons
Contact Now

ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal

Description
Structure: Horizontal Or Vertical Type Vessels Working Years Design: 20years
Machinery Test Report: Provided Max Working: 3 MPa
Inner Cylinder Material: S30408 Height: 1800-2450mm
Geometric Volume: 10m3/20m3 Other Name: Cryogenic Liquid Co2 Gas Storage Tank
Custom Design: Provided Pressure Rating: High Pressure
Capacity: 5000 Liters Valve Type: Cryogenic Valve
Highlight:

ASME certified cryogenic storage tank

,

5000L cryogenic storage tank

,

3MPa horizontal cryogenic tank

ASME Certified Horizontal Welded Cryogenic Storage Tank
Product Description

Our ASME certified cryogenic liquid storage tanks are precision-engineered pressure vessels manufactured in strict compliance with:

  • TSG21-2016 (Stationary Type Pressure Vessels Safety Technical Supervision Rules)
  • GB/T150-2011 (Pressure Vessels)
  • GB/T18442-2019 (Stationary Vacuum Insulation Cryogenic Pressure Vessel)

These double-wall horizontal/vertical tanks feature vacuum powder insulation for superior performance:

  • Compact structural design
  • Exceptionally low daily evaporation rate
  • Space-efficient footprint
  • Centralized control system
  • Safe and reliable operation
  • Easy maintenance
Product Parameters
Working Pressure (Mpa) Working Medium Volume (m³) Weight (kg) Outside Size (mm)
0.8LOX/LN₂/LAr54160Φ1900×5115
0.8LOX/LN₂/LAr106035Φ2200×6035
0.8LOX/LN₂/LAr158196Φ2300×7730
0.8LOX/LN₂/LAr209715Φ2600×7655
0.8LOX/LN₂/LAr3013270Φ2600×10605
0.8LOX/LN₂/LAr5021725Φ3200×11670
0.8LOX/LN₂/LAr10043386Φ3600×16550
0.8LOX/LN₂/LAr15061500Φ3800×22000
0.8LOX/LN₂/LAr20076800Φ4000×25300
1.6LOX/LN₂/LAr54650Φ1900×5115
1.6LOX/LN₂/LAr106850Φ2200×6035
1.6LOX/LN₂/LAr159780Φ2300×7730
1.6LOX/LN₂/LAr2011450Φ2600×7655
1.6LOX/LN₂/LAr3015790Φ2600×10605
1.6LOX/LN₂/LAr5026500Φ3200×11670
1.6LOX/LN₂/LAr10053300Φ3600×16550
2.16LCO₂55200Φ1900×5115
2.16LCO₂107860Φ2200×6030
2.16LCO₂1510087Φ2400×7020
2.16LCO₂2012740Φ2500×8120
2.16LCO₂3017165Φ2900×8550
2.16LCO₂5028644Φ3100×11500
2.16LCO₂10057550Φ3500×16450
2.16LCO₂15082460Φ3900×19000
ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal 0 ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal 1 ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal 2
Structure and Materials

Our cryogenic tanks feature a robust double-layer construction:

  • Inner Tank: Constructed from stainless steel or aluminum alloy for superior low-temperature toughness and corrosion resistance
  • Outer Tank: Made of carbon steel or stainless steel for structural integrity and external protection
  • Insulation: High-performance vacuum powder or multi-layer insulation materials between walls to minimize heat transfer
Thermal Insulation Performance

Advanced insulation technologies ensure optimal performance:

  • High-vacuum insulation systems
  • Multi-layer reflective screen insulation
  • Powder insulation materials
  • Exceptionally low daily evaporation rates
  • Extended liquid storage duration
  • Reduced operational costs
Safety Features

Comprehensive safety systems for reliable operation:

  • Pressure relief valves for automatic pressure regulation
  • Explosion-proof discs as secondary safety measures
  • Precision liquid level gauges
  • Real-time temperature monitoring systems
  • Automatic alarm systems
  • Overfill protection mechanisms
Contact Us for Specifications

For detailed technical specifications and pricing information:

Email: info@gneeheatex.com

WhatsApp: +8615824687445
