50m3 8bar ASME Stainless Steel Cryogenic Storage Tank

50m3 8bar ASME Stainless Steel Cryogenic Storage Tank
50m3 8bar ASME Stainless Steel Cryogenic Storage Tank 50m3 8bar ASME Stainless Steel Cryogenic Storage Tank 50m3 8bar ASME Stainless Steel Cryogenic Storage Tank 50m3 8bar ASME Stainless Steel Cryogenic Storage Tank

Large Image :  50m3 8bar ASME Stainless Steel Cryogenic Storage Tank

Product Details:
Place of Origin: CHINA
Brand Name: GNEE
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: ≥1sets
Price: depend on product
Packaging Details: Cylindrical packaging / Airbag packaging
Payment Terms: D/A,D/P,T/T,Western Union,MoneyGram,L/C
Contact Now

50m3 8bar ASME Stainless Steel Cryogenic Storage Tank

Description
Highlight:

ASME stainless steel cryogenic tank

,

8bar cryogenic storage tank

,

50m3 cryogenic storage tank

50m³ 8bar ASME Standard Stainless Steel Cryogenic Storage Tank
Product Description
Cryogenic storage tanks are specially designed for storing cryogenic liquids including liquid oxygen (LOX), liquid nitrogen (LIN), liquid argon (LAr), liquefied natural gas (LNG), liquid carbon dioxide, and nitrous oxide. These tanks are suitable for container systems in maritime, railway, and road transportation worldwide.
Available in specifications ranging from 20 to 50 cubic meters, these tanks utilize high-vacuum multi-layer winding insulation technology for optimal performance.
With the widespread adoption of liquefied natural gas (LNG), cryogenic storage tanks have become increasingly popular in the LNG industry. Compared to traditional LNG carriers and natural gas pipelines, these tanks offer:
  • Convenient transportation
  • Lower investment costs
  • Shorter implementation cycles
  • Reduced maintenance expenses
Product Parameters
Water Capacity Working Pressure (MPA) External Dimension (mm) Net Weight (kg) Full-load Weight (kg)
5m³ 1 2216×4405 4130 9830 (LOX), 8180 (LIN), 11130 (LAr)
5m³ 1.75 2216×4405 4400 10100 (LOX), 8450 (LIN), 11400 (LAr)
10m³ 1 2216×7098 6250 17920 (LOX), 14620 (LIN), 20520 (LAr)
10m³ 1.75 2216×7098 6861 18261 (LOX), 14961 (LIN), 20861 (LAr)
15m³ 0.8 2616×6520 7380 24480 (LOX), 22530 (LIN), 28380 (LAr)
15m³ 1.75 2616×6520 8501 25601 (LOX), 20651 (LIN), 29501 (LAr)
20m³ 0.8 2616×8030 8925 31725 (LOX), 25125 (LIN), 36925 (LAr)
20m³ 1.75 2616×8030 10378 33178 (LOX), 26578 (LIN), 38378 (LAr)
30m³ 0.8 2616×11070 12166 46366 (LOX), 36466 (LIN), 54166 (LAr)
30m³ 1.75 2616×11070 14300 48500 (LOX), 38600 (LIN), 56300 (LAr)
50m³ 0.8 3020×12685 19494 76494 (LOX), 59994 (LIN), 89494 (LAr)
50m³ 1.75 3020×12685 23050 80050 (LOX), 63550 (LIN), 93050 (LAr)
100m³ 0.8 3520×17585 33800 147800 (LOX), 114800 (LIN), 174800 (LAr)
100m³ 1.6 3520×17585 40550 154550 (LOX), 121550 (LIN), 181550 (LAr)
Our Advantages
  • 17+ years of manufacturing experience with our own factory
  • OEM customization available according to your specifications
  • Professional R&D and QC teams ensuring product quality
  • Comprehensive service from production to packaging
  • High-quality products at competitive prices with timely delivery
  • Dedicated sales team providing responsive support
For customized solutions based on your specific requirements (storage capacity, media type, etc.), please contact our team:
Email: info@gneeheatex.com
WhatsApp: +86 158 2468 7445

Tag:

25m3 Cryogenic Storage Tank,

Vacuum LNG storage facilities,

2.16mpa liquid nitrogen storage container
